MANUALE ERPICI PIEGHEVOLI DJ-DP-DK-DMAX
 Avoid to turn empty (outside of the land) with the machine. During the job avoid to carry out curves with the buried machine,
much less to work when you go behind.
 Lift always for the changes of direction and the reversals of march.
 During the transport, or every time the raising of the machine becomes necessary, is opportune that the lifter of the tractors
comes regulated so that the same machine is not raised from earth in order more than 35 cm approximately.
Avoid to go on public roads with the dirty machine of earth, grass or other that produce soil and prevent to the street traffic.

Not decrease with violence the machine on the land but to make it slowly in order to concur graduates them insertion of the
blades in the land.
 In contrary case the components of the same machine would provoke strong sollicitations on all who could compromise of
their integrity.
 In phase of transport on road, with the raised machine, to put in position dl block the command lever d of the hydraulic lifter of
the tractor.
Before inserting the power take off, assess of the number of turns defined.

Do not exchange the regimen of 540 turns/min with 1000 turns/min.

 The installation and the taking apart of the cardan shaft always must be made with turned off motor.
 Use only the universal joint suppplied by the manufacturer and provided with the overload safety devices.
The protection device of the cardan shaft must be always efficient and has to be checked at

regular intervals and fixed by means of chains in order to avoid shiftings.
 Always disconnect the power takeoff when the cardan shaft forms an angle exceeding 15°, see
figure.
 Before inserting the power take off make sure that there are not persons or animals in the action zone and that the chosen
regimen corresponds to that one concurred. Never exceed the previewed.
 In order to avoid burnings do not touch the speed gear after a protracted use of the machine.
 Before change speed gearbox, disengage the power takeoff, switch off the tractor
engine, activate the tractor parking brake and lock the rear cover of gearbox.Not
use the machine inside of structures sluices than there is not one adapted
ventilation.
While the machine is opened and closed, make sure there are no persons, animal

or things within the operation range of the machine

3.2. MAINTENANCE IN SAFETY

 Do not allow unauthorized persons to perform maintenance operations or any other kind of intervention on the machine.
Maintenance and repairing operations must be carrie on in workshop fit for those purposes.

 Always use original accessories and spare parts in order to comply with the requirements of the manufacturer, otherwise,
any guarantee may be declined and some malfunctionings may arise impairing the safety of the machine.
In case of maintenance of the machine disconnect hydraulic the tube from plug of the tractor

 Respect the conformity of oils advises to you.
In performing any operation on the machine, disconnect the power takeoff of the tractor, activate the parking brake, remove

the start-up key and do not allow any person to get onto the tractor.
Before cleaning or greasing the cardan shaft disconnect the power takeoff, switch off the engine, activate the parking brake

and remove the start-up key.
Copyright ©2009 della Alpego spa® - All rights are reserved. Reprinting or unauthorized use of this manual is strictly forbidden without written permission by Alpego spa
Old Cod.D03214
Q00A00017 R.23
SAFETY RULES
- 11
