2.1. DESCRIPTION OF THE MACHINE

ROTODENT FOLDING rotary harrows must be used to treat only agricultural lands, in particular to prepare the seed-beds, any
other usage is forbidden.
ROTODENT FOLDING rotary harrows are machines design to limit the overall transport dimension to only
250 cm. and to adapt at conformation of the soil.
ROTODENT FOLDING rotary harrows are machines driven by the tractor power plug and by a full-geared driving mechanism
transmitting the motion to a series of in-line blades-holders, each provided with two blades.
MODEL A (mm)
DJ-360 3686
DJ-400 4150
DJ-460 S 4625
DJ-500 S 5094
DP-400 4140
DP-450 4600
DP-500 5080
DP-600 6020
DK-400 4140
DK-450 4600
DK-500 5080
DK-600 6020
DK-700 6960
DmaX -450 4620
DmaX -500 5090
DmaX -600 6030
DmaX-700 6970
DmaX-800 7910
