2.4. UNIVERSAL JOINT IDENTIFICATION

The machine is supplied provided with universal joint with safety device against the overloads as shown
in the figure; it is forbidden to replace this joint with any other type of universal joints differing from the
original one. Read carefully the instructions contained in the booklet accompanying the universal joint.
Pay attention: don't exchange the side universal joint with the central one
DJ
DJ-SUPER
DP
DK
DmaX
450-500-600
DmaX
700-800
LATERAL UNIVERSAL JOINT WITH SHEAR BOLT SAFETY SYSTEM
DJ
DJ-SUPER
DP
DK
Copyright ©2009 della Alpego spa® - All rights are reserved. Reprinting or unauthorized use of this manual is strictly forbidden without written permission by Alpego spa
CENTRAL UNIVERSAL JOINT
Old Cod.D03214
Q00A00017 R.23
TECHNICAL FEATURES
