English
Fig. 2
Switches and connectors
at the receiver AV-R(r)
(backside)
Fig. 3
Pin configuration for
external loudspeakers
Special features of the
AV-Rr-2 receiver
E-V-2
AV-R(r)
AV-Rr
S/N: 070XXX
Optical
(9)
Out In
Ch1
Optical
(12)
Out In
Ch2
The version AV-Rr-2 has all inputs (9 and 12) for the operation of an
additional camera twice (the channel can be chosen with switch (7)
at the front side, fig. 1). With the optional VGA-output (13) the
receiver can be connected directly to a VGA-monitor (e.g. TFT).
Two-channel receivers AV-Rr-2 have an additional switch on the
front to change the active channel for audio output with the internal
loudspeaker and the remote control. In position Ch1 the camera with
the ID 1 can be controlled and the audio signal of the camera at the
Ch1 optical input at the backside is put out with the internal
loudspeaker. In position Ch2 camera 2 can be controlled and audio
signals of the Ch2 optical input are put out.
On the backside there are two sets of connectors for Ch1 and Ch2.
They have the same function as at the single channel receiver.
VGA
Out
(13)
Video Audio Out
Out L R
Video Audio Out
Out L R
(11)
ground
right channel
mk-messtechnik
(10)
DC In
(8)
6V
300 mA
Speaker
Out
