III Extra small camera AV-Cm
Figure 1 shows the option of the providable mini video-camera with
the lens (1), the mounting clip (2), and the tripod socket (3). The
mounting (4) is adjustable and can be changed to fit the
requirements. The horizontal axis of the camera can be changed by
the swivel joint (5).
By turning the lens, the requested distance/sharpness can be set.
The camera is supplied by the transmitter which reduces the latter
one's operating time to a small degree.
(4)
(1)
(2)
(3)
AV-Cm
(2)
(1)
(3)
(4)
Fig. 1
Mini camera, mounted on
the steering wheel
(5)
