IX-4
Camera Menu
set function.
① Digital ZOOM" can be set to "OFF", X2, X4, X6, X8, or X10.
"ZOOM Speed": Set the speed of the zoom.
"FOCUS Speed": Set the speed of focus.
"ZOOM": Lens ZOOM adjust "WIDE" / "TELE"
"FOCUS": "AUTO" / "MANUAL"
Having adjusted the settings (and confirmed with [Enter]), push [Esc] to go back to the
main menu page.
[07]. REV. SELECT MENU
R E V
→ P O S I / N E G A
①
→ P O S I
N E G A
H R E V → O F F
②
V R E V → O F F
③
This is used to select image "Positive", "Negative" & "Horizontal Reverse" and "Vertical
Reverse" function.
① POSI/NEGA": Set image as positive & negative.
② H.REV": Horizontal Reverse (Mirror) "ON/OFF"
③ V.REV": Vertical Reverse (Up-side down) "ON/OFF"
Having adjusted the settings (and confirmed with [Enter] ), push [Esc] to go back to the
main menu page.
[08]. POSITION SELECT MENU
P O S I T I O N
→ A L A R M
①
F r e e z e
②
P O S I T I O N
③
→ N O = 6 4
Z O O M
F O C U S
Z O O M
F O C U S
This is used to set the "ALARM-IN" function, either as "ALARM POSITION" or "IMAGE
FREEZE".
"ALARM NO": Set alarm position (1~64); if set to (0), alarm position is not enabled.
"Freeze": Set "ON" mode, "ALARM-IN" freezes trigger input.
"POSITION": The alarm position has 64 steps (positions) which can be programmed.
By this program, the zoom & focus may go to the exact position it is programmed to.
Having adjusted the settings (and confirmed with [Enter] ), push [Esc] to go back to the
main menu page.
[09]. TITLE SELECT MENU
T I T L E
①
→
→ 0 1 2 3 4 5 6 7 8 9
②
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
a b c d e f g h i j k l m
O N
O N
N O = 0
O F F
O N
S p e e d - - ■ - -
S p e e d - - ■ - -
W I D E T E L E
I N F N E A R
