Camera Menu
the picture signal or the light rate of the peak.
②"ALC" is used to select "AUTO" or "FIX". Adjust IRIS level.
FIX has to be selected to use the Brightness-control of the camera!
③"AES" is used to set electronic shutter as "AUTO" or "FIX". At "AUTO" mode the AES level
can be adjusted, at FIX mode the shutter speed can be fixed as [OFF], [1/100sec],
[1/250sec], [1/500sec], [1/1000sec], [1/2000sec], [1/4000sec], or [1/10000sec].
Having adjusted the settings (and confirmed with [Enter]), push [Esc] to go back to the
main menu page.
[02]. BLC SELECT MENU
B L C
① → O F F
O N
→ A R E A
②
S E N S L O W
③
This is used to control "BLC" (Back Light Compensation),
①"BLC": Set to „ON" / "OFF".
Selector "ON" has 2 sub-items: "AREA" and "SENS".
②"AREA": 48 BLC zones can be set separately. Set the iris and shutter speed according to
the mask area (BLC zone).
③"SENS" is used to enhance the BLC effect.
Having adjusted the settings (and confirmed with [Enter]), push [Esc] to go back to the
main menu page.
[03]. AGC, SENS SELECT MENU
A G C S E N S
→ F r e e z e
①
F r e e z e
②
P r i o r i t y → A G C
③
A G C
④
S E N S
⑤
This is used to select "FREEZE" and "Priority" & "AGC" and "SENS" function.
① "FREEZE": The display mode of the freeze image can be chosen as "Field" or "Frame".
"FREEZE": "ON" (Freeze) / "OFF" (Do not freeze).
"Priority": Select priority as "AGC" or "SENS".
"AGC": Adjust auto gain control as 0dB, 2.25dB, 4.5dB, 6.75dB, 9dB, 11.25dB, 13.5dB,
15.75dB, or 18dB. 9 steps adjustable.
"SENS": For low light application: 0 Frame, 6 Frame, 12 Frame, 16 Frame, 18 Frame, 22
Frame, 24 Frame, 30 Frame, or 36 Frame. 9 steps adjustable.
Having adjusted the settings (and confirmed with [Enter]), push [Esc] to go back to the
main menu page.
- - - ■ - - - -
→ F i e l d
F r a m e
→ O F F
O N
S E N S
A U T O - - - - ■ - - - -
A U T O - - - - ■ - - - -
