[04]. COLOR SELECT MENU
C O L O R
→ C O L O R → O F F
①
W B → A T W
②
G A I N → R - Y
③
This is used to set the color "ON"/"OFF", the white balance (WB), and the gain rate of the
colors RED & BLUE.
"COLOR": The mode "OFF" has a monochrome image. "ON" is normal color image. "AUTO"
is at low light.
If AGC is high, display image will automatically change to a monochrome image.
"WB" (White balance control): "ATW" will auto-adjust white balance, can be set to offset
level. "AWB" is one push white balance. Push [Enter] and the "AWB" will start to flicker;
until flickering stops it will lock the current color temperature at the same time.
"GAIN": The gain rate of R-Y & B-Y can be adjusted separately.
Having adjusted the settings (and confirmed with [Enter] ), push [Esc] to go back to the
main menu page.
[05]. APC SELECT MENU
A P C
→ H G A I N
①
V G A I N
②
This is used to enhance the compensation of the picture quality.
①"H • GAIN": Horizontal Compensation.
"V • GAIN": Vertical Compensation.
Having adjusted the settings (and confirmed with [Enter]), push [Esc] to go back to the
main menu page.
[06]. LENS SELECT MENU
L E N S
→ D i g i t a l
①
Z O O M
②
F O C U S
③
Z O O M
④
F O C U S
⑤
→ M A N U A L
A U T O
This is used to control the montion of the lens, including "Digital ZOOM" ON/OFF and time
Camera Menu
O N
A U T O
R - - - - ■ - - - - B
A W B R - - - - ■ - - - - B
- - - - ■ - - - -
B - Y - - - - ■ - - - -
- - - - - - ■ - - - - - -
- - - - - - ■ - - - - - -
Z O O M → O F F
S p e e d - - ■ - -
S p e e d - - ■ - -
W I D E T E L E
I N F N E A R
