1.2 Specifications
Platform
CPU
Chipset
Memory
* 4500+(OC) memory frequency can only be achieved when a
single memory module is installed (Single channel memory).
more information. (http://www.asrock.com/)
Expansion
Slot
* Supports NVMe SSD as boot disks
• Micro ATX Form Factor
• Supports 6 th
Generation Intel® Core
Celeron® Processors (Socket 1151)
• Digi Power design
• 14 Power Phase design
• Supports Intel® Turbo Boost 2.0 Technology
• Supports Intel® K-Series unlocked CPUs
• Supports ASRock BCLK Full-range Overclocking
• Supports ASRock Hyper BCLK Engine
• Intel ®
Z170
• Dual Channel DDR4 Memory Technology
• 2 x DDR4 DIMM Slots
• Supports DDR4 4500+(OC)*/4366(OC)/4333(OC)/4266
(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/
3666(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3300
(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2600(OC)/
2400(OC)/2133 non-ECC, un-buffered memory
• Supports ECC UDIMM memory modules (operate in non-
ECC mode)
* Please refer to Memory Support List on ASRock's website for
• Max. capacity of system memory: 32GB
• Supports Intel® Extreme Memory Profile (XMP) 2.0
• 15μ Gold Contact in DIMM Slots
• 3 x PCI Express 3.0 x16 Slots (PCIE1/PCIE2/PCIE3: single
at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE2); triple at x8
(PCIE1) / x8 (PCIE2) / x4 (PCIE3))*
• Supports AMD Quad CrossFireX
• Supports NVIDIA® Quad SLI
• 15μ Gold Contact in VGA PCIe Slot (PCIE1)
TM
i7/i5/i3/Pentium®/
TM TM
and CrossFireX
TM TM
and SLI
