Connector
BIOS
Feature
10
• 1 x COM Port Header
• 1 x Power LED and Speaker Header
• 2 x CPU Fan Connectors (1 x 3-pin, 1 x 4-pin) (Smart Fan
Speed Control)
• 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed
Control)
* CPU_FAN1, CHA_FAN_1, CHA_FAN_2 and CHA_FAN_3
can auto detect if 3-pin or 4-pin fan is in use.
* The CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
• 1 x 24 pin ATX Power Connector
• 1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
• 1 x Front Panel Audio Connector
• 1 x Thunderbolt 2/3 AIC Connector (5-pin)
• 1 x Thunderbolt 3 AIC Connector (10-pin)
* Only one Thunderbolt AIC Card is supported.
• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports
ESD Protection (ASRock Full Spike Protection))
• 1 x Dr. Debug with LED
• 1 x Power Switch with LED
• 1 x Reset Switch with LED
• V-Probe TM
: 1 x 7-set of onboard voltage measurement points
laid
• Rapid OC Buttons: +/- buttons to adjust OC frequency
• 1 x Menu Button
• Post Status Checker (PSC)
• 1 x Slow Mode Switch
• 1 x LN2 Mode Switch
• 1 x BIOS Selection Switch
• 1 x XMP Switch
• 1 x Direct Key Button
• 2 x 128Mb AMI UEFI Legal BIOS with multilingual GUI
support (1 x Main BIOS and 1 x Backup BIOS)
• Supports Secure Backup UEFI Technology
• ACPI 5.0 Compliant wake up events
• SMBIOS 2.7 Support
• CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO,
VCCPLL, VCCSA Voltage Multi-adjustment
