No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
3 CPU Fan Connector (CPU_FAN2)
4 V-Probe
5 Power Switch (PWR)
6 Reset Switch (RST)
7 Rapid OC Button (+) (PLUS)
8 Rapid OC Button (–) (MINUS)
9 Menu Button (MENU)
10 ATX Power Connector (ATXPWR1)
11 USB 3.0 Header (USB3_5_6)
12 Post Status Checker (PSC)
13 LN2 Mode Switch (LN2MODE1)
14 Direct Key Button (DIRKEY1)
15 Slow Mode Switch (SLOWMODE1)
16 XMP Switch (XMP_ON1)
17 SATA3 Connector (SATA3_A2)
18 SATA3 Connector (SATA3_A1)
19 Chassis Fan Connector (CHA_FAN1)
20 SATA3 Connector (SATA3_0)
21 SATA3 Connector (SATA3_2)
22 SATA3 Connector (SATA3_1)
23 SATA3 Connector (SATA3_3)
24 SATA Express Connector (SATA_EXP0)
25 SATA Express Connector (SATA_EXP1)
26 SATA3 Connector (SATA3_5)
27 SATA3 Connector (SATA3_4)
28 System Panel Header (PANEL1)
29 BIOS Selection Switch (BIOS_SEL1)
30 Chassis Fan Connector (CHA_FAN2)
31 COM Port Header (COM1)
32 USB 2.0 Header (USB5_6)
2
TM
(VOL_CON1)
