2.7 Smart Switches

The motherboard has eleven smart switches: Power Switch, Reset Switch, Clear
CMOS Switch, Rapid OC Buttons, Menu Button, Slow Mode Switch, BIOS Selection
Switch, LN2 Mode Switch, Direct Key Button and XMP Switch.
Power Switch
(PWR)
(see p.1, No. 5)
Reset Switch
(RST)
(see p.1 No. 6)
Clear CMOS Switch
(CLRCBTN1)
(see p.4, No. 15)
This function is workable only when you power off your computer and unplug the power
supply.
+ / - Rapid OC
Buttons
(PLUS: see p.1, No. 7)
(MINUS: see p.1, No.
8)
This overclocking behavior depends on the system configuration, such as memory capabil-
ity, thermal solution, etc. Overclocking may affect your system stability, or even cause dam-
age to the components and devices. We are not responsible for possible damage caused by
overclocking.
Menu Button
(MENU: see p.1, No.
9)
26
Power
Reset
+
-
MENU
Power Switch allows users to
quickly turn on/off the system.
Reset Switch allows users to
quickly reset the system.
Clear CMOS Switch allows
users to quickly clear the
CMOS values.
+ / - Rapid OC Buttons allow
users to quickly and easily
adjust OC frequency in Rapid
OC.
MENU Button allow users to
quickly toogle among Date/
Time, Temperature, and Volt-
age information.
