Print Settings

Keys: ,
Speed
Contrast
Key:
Transfer ribbon control
Key:
X displacement
Machine Parameters
Keys: , ,
Continuous Mode
Mode
Key:
Print offset
Key:
Print position
Key:
Layouts/cycle
Key:
Check speed on start
112
Intermittent mode only
Indication of print speed in mm/s.
The print speed can be determined for each print order anew. The setting of print speed affects
also the test prints.
Value range: 50 mm/s ... 400 mm/s (see the technical data).
Indication of value to set the print intensity when using different materials, print speeds or printing
contents.
Value range: 10% ... 200 %.
Examination if the transfer ribbon roll is to end or if the ribbon was torn at the unwinding roll.
Off: The ribbon control is deselected, i.e. the direct print module continues without an error
message.
On: The ribbon control is selected, i.e. the current print order is interrupted and an Error Message
appears at the display.
strong sensibility: The direct print module reacts immediately to the end of the transfer ribbon.
weak sensibility: The direct print module reacts at approx. 1/3 more slowly to the end of the
transfer ribbon.
Displacement of the complete print transverse to the paper direction.
The displacement is possible only up to the edges of the printing zone and is determined by the
width of the focal line in printhead.
Value range: −90.0 ... +90.0.
Selection of operating mode (IO static, IO static continuous, IO dynamic, IO dynamic continuous,
test mode direct start).
Indication of distance of the layout (res. the first layout in case more layouts per cycles are to be
printed) to the zero point of machine.
Settings possible either in mm or ms.
Value range: 1 ... 999 mm
Indication of start position of print carriage in mm.
Value range: 12 ... 43 mm
Indication of the number of printed layouts per print start (cycle).
Value range: 1 ... 25.
Off: Material speed is only checked if the set offset value is taken into consideration. It is
possible to activate print start signal although the material is not yet in move. However, until the
end the material speed has to be inside the valid speed sector as otherwise the print order is
cancelled.
On: Material speed is checked at print start signal. Is the material speed outside of the valid
speed sector then the start signal is ignored.
Default: Off
