Technical Data - Carl Valentin FLEXICODE Schnellreferenzhandbuch

Flexicode

Technical Data

Print resolution
Print speed
Back speed
Print width
Print length
Frame passage width
Printhead
Acoustic emission (measuring distance 1 m)
Average sound pressure level
Transfer ribbon
Ink
Roll diameter
Core diameter
Length
Width
Dimensions (width x height x depth)
Print mechanics
without mounting frame
with mounting frame
Control unit
Weight
Print mechanics
Electronics with cable
Electronics
Processor
RAM
Slot
Print memory
Battery cache
Warning signal
Interfaces
Serial
Parallel
USB
Ethernet
2 x USB Master
Connection values
Pneumatic connection
Air consumption typical*
* hub 1,5 mm
150 cycle/minute
6 bar operating pressure
Nominal voltage
Fuse values
128
Flexicode 53
300 dpi
50 ... 400 mm/s
intermittent mode only: max. 600 mm/s
53 mm
continuous mode: max. 3000 mm
intermittent mode: max. 40 mm
customized
Corner Type
69 dB(A)
outside / inside
max. 82 mm
25,4 mm / 1"
max. 450 m
max. 55 mm
190 mm x 180 mm x 208 mm
depends on passage width
242 mm x 117 mm x 220 mm
connecting cable set to mechanics 2.5 m
6,0 kg
3,7 kg
High Speed 32 Bit
16 MB
Compact Flash card type I
max. 16 MB
for Real-Time clock (storage of data with shut-down)
accoustic signal when error
RS-232C (up to 115.200 Baud)
SPP
2.0 High Speed Slave
10/100 Base T, LPD, RawIP-Printing, DHCP, HTTP, FTP
connection for external USB keyboard and memory stick
min. 6 bar dry and free from oil
150 ml/min
230 V / 50 ... 60 Hz 1.5 A
115 V / 50 ... 60 Hz 3 A (option)
2x T4A 250 V
English
