Ribbon Save - Continuous Mode - Carl Valentin FLEXICODE Schnellreferenzhandbuch

Flexicode
Key:
Rotate layout
Key:
Alignment
Ribbon save
Keys: , , ,
Continuous Mode
Mode
Key:
Transfer ribbon correction
Key:
Performance information
Key:
Expert parameters
Key:
Printhead down time
Ribbon motor early start
time
Key:
Minimal print speed
Maximum print speed
114
According to standard the layout is printed ahead with a rotation of 0°. If the function is
activated, the layout is rotated by 180° and printed in reading direction.
The adjustment of layout is effected only after 'flip/rotate layout', i.e. the adjustment is
independent of the functions flip and rotate.
Left: The layout is aligned at the left-most position of printhead.
Centre: The layout is aligned at central point of printhead.
Right: The layout is aligned at right-most position of printhead.
,
Selection of ribbon save mode.
Off: Ribbon save set to Off.
Standard: Maximum ribbon save performance, i.e. with this setting there is no loss of transfer
ribbon (apart from the safety distance of 1 mm, so the print fields are not printed one into the
other).
0 mm = It is always so far retracted that an optimal ribbon save is reached (no loss of transfer
ribbon).
Default: -1 mm
−xx mm = The feedback can be made smaller.
+xx mm = The feedback can be made larger.
sa/mm: The smallest possible distance of two prints with full ribbon save
cmin: Max. number of cycles per minute.
so/mm: Indicates the loss of ribbon save
Password protected menu
Enter password, press key
indicated.
PhDownT = printhead down time in ms:
Is used from ribbon save algorithm to use for the calculation of start time of printhead downward
movement.
REStartT = ribbon motor early start time in ms:
This value is added to the acceleration time of transfer ribbon movement. Time indication for the
time between 'motor reached material speed' and 'printhead burns'.
MinSpeed = minimal print speed:
If the min. print speed is increased, the max. number of cycles is also increased.
USMxSped = use maximum speed:
Use the speed parameter as maximum speed. If the material speed exceeds the maximum
speed the print is interrupted as long as the material speed is again under the maximum speed.
English
to confirm the entry and the following parameters are
