Relay K2
Function
X1.3/K21 Relay output
normally−closed
contact
X1.3/K22 Relay mid−position
contact
X1.3/K24 Relay output
normally−open
contact
PES HF shield termination by PE connection through shield clamp
)
Note!
ƒ
ƒ
ƒ
ƒ
ƒ
ƒ
EDK82EV903 DE/EN/FR 4.0
Relay position
switched
opened
closed
Switching of control signals:
– Use shielded cables
– HF shield termination by PE connection
– The minimum load for switching the signals through correctly is 12 V and
5 mA. Both values have to be exceeded at the same time.
Switching of mains potentials:
– Unshielded cables are sufficient
For the protection of the relay contacts a corresponding suppressor circuit is
absolutely required for an inductive or a capacitive load!
The service life of the relay depends on the type of load (ohmic, inductive or
capacitive) and the value of the switching capacity.
The output message can be changed with C0409.
If you use an application I/O function module:
– The relay K2 is only active with application I/O E82ZAFAC from version
Vx21 onwards.
l
Electrical installation
Connection of relay output K1 and K2
Message
(Lenze setting)
not assigned
not assigned
5
Technical data
AC 250 V/3 A
DC 24 V/2 A ... DC 240 V/0.22 A
