Lenze 8200 vector Montageanleitung Seite 172

6 Extensions for automation
Modules
Mounting and dismounting function modules
)
Note!
ƒ
ƒ
172
Keep the blanking cover 1 and the FIF protection cover 2 so that you can
attach them again after you have dismounted the function module.
– Without the FIF cover 2, the controller is inhibited.
– If no function module is plugged on, the controller without FIF cover 2 and
blanking cover 1 must not be commissioned (dangerous electrical voltage
at the FIF interface).
When two function modules are operated, make sure that the two
terminals X3/28 (controller inhibit) of the interfaces FIF I and FIF II are
AND'ed internally and must be wired according to their
application.(¶ 175).
l
EDK82EV903 DE/EN/FR 4.0
