LOADING THE COT INTO A VEHICLE WITH TWO OPERATORS - POWERED METHOD (CONTINUED)
8 . Load the cot either from the foot end or with one operator at the foot end and one on the side:
With both operators at the foot end (preferred method):
• Both Operators − Grasp the cot frame at the foot end .
• Operator 1 − Press the retract (–) button until the undercarriage of the cot retracts fully (Figure 21) .
Figure 21: 2 Operators (Foot End) - One Pressing
the Retract Button
With one operator at the foot end and one on the side:
• Operator 1 − Grasp the cot frame at the foot end and press the retract (–) button until the undercarriage of
the cot retracts fully (Figure 23) .
• Operator 2 − Securely grasp the cot outer rail to stabilize the cot during retraction .
Figure 23: 2 Operators (Foot End and Side) - One
Pressing the Retract Button
9. Both Operators − Push the cot into the patient compartment as shown in Figure 22 or Figure 24 until the cot
engages the cot fastener (not included) .
WARNING
When using a cot fastener, do not load the cot into the vehicle with the head section retracted . Loading the cot with the
head section retracted may cause the product to tip or not engage properly in the cot fastener, possibly causing injury
to the patient or operator and/or damage to the cot .
www.stryker.com
Operation Guide
Figure 22: 2 Operators (Foot End) Loading the Cot
Figure 24: 2 Operators (Foot End and Side) Loading
6506-009-005 REV B
the Cot
