• Attach the on/off switch (3) of the speed controller to the RC board with a strip of double-sided adhesive tape (e.g.
servo tape) or a strip of hook-and-loop tape.
If the receiver connection line of the speed controller has wrapped-in ferrite cores, they serve to suppress
interferences and must be placed as closely as possible to the receiver plug.
Loose cables should be bundled with a cable tie to prevent them from getting into the servo's rudder linkage
in driving operation.
• Figure 5, item 3 shows assembly of a receiver battery and an on/off switch for the receiver system (figure 5, item 4).
Connect the cable of the on/off switch to the battery connection of the receiver. For this, observe the operating
instructions for the remote control system.
d) Mounting the Receiver Aerial
According to the remote control system used (27 or 40 MHz or 2.4 GHz), you need to install the receiver in the RC
plate according to the information in the operating instructions. Figure 3, item 1 shows a possible installation site for a
2.4 GHz remote control. Observe the following notes for installation of the receiver aerial.
Modern remote control systems in 2.4 GHz technology only require short aerials at the transmitter and
receiver for secure operation. Only the few centimetres without insulation are the receiver aerial. The remaining
part of the aerial cable serves as supply/extension so that you can pull an aerial from a body.
For secure reception, it is perfectly sufficient if the last three centimetres of the receiver aerial in the body are
placed vertically in the body, e.g. with a short piece of Bowden tube glued into the body (figure 3, item 6).
If you use a 27 or 40 MHz-remote control, we urgently recommend guiding the receiver aerial vertically up
from the boat body with a Bowden tube of a sufficient length.
Important!
The remote control range may be reduced drastically if the receiver aerial is not placed correctly (e.g. if the
aerial is only in the boat's body). In this case, the model can no longer be controlled. Check that the receiver
aerial is placed correctly before every operation.
29
