e) Inspecting the Ship Propeller
Check the ship's propeller and its counter-nut for tight fit and damage before any voyage. A damaged ship's propeller
must be replaced before operation. If this is not observed, the ship's propeller may come loose or break apart unintended
in operation. There is a danger of further damage to your model. The model will also no longer be controllable.
On the ship's propeller, also observe further information in the chapter „Replacing the Ship's Propeller".
Attention!
The ship propeller is very sharp-edged and may cause injury and/or property damage when handling, replacing
and in operation!

f) Boat Rack Installation

The scope of delivery includes a boat rack of wood
that has to be assembled and glued together first.
Build the boat rack of the four wood parts as shown
in figure 4.
The side parts (figure 4, item 1) must be built so that
the wide side points down.
The side parts are attached into the long parts (figure
4, item 2).
Glue the wood parts on with a drop of viscous in-
stant adhesive or some 5-minute epoxy glue.
30
Figure 4
