I
dentifikation des Gerätes und des Herstellers
Die in diesem Handbuch enthaltenen technischen Daten ersetzen nicht
die Angaben auf dem Typenschild.
Die an dem Wechselrichter angebrachten Schilder dürfen NICHT entfernt, beschädigt, be-
schmutzt oder verdeckt werden.
Das Zulassungsschild enthält folgende Informationen:
1. Hersteller
2. Modell
3. Nenndaten
4. Zertifizierungen
© Copyright 2014 Power-One Italy Spa. All rights reserved. Reproduction, use or disclosure to third parties without express written authority
Sie dürfen NICHT von anderen Objekten (Lappen, Kästen, Anbauten usw.) verdeckt werden.
Sie müssen regelmäßig gereinigt werden und immer sichtbar sein.
