BrAKE CONTrOL AND TEMPErATUrE DETECTION FOr K AND A CONTrOL
4.3.2 Specification and connection of the temperature detection
DANGEr
NOTICE
A switchable evaluation is implemented in the KEB COMBIVERT. The desired operating
mode can be adjusted via software (dr33).
Operating mode
(dr33)
0 KTY84/130
1
2 Via encoder
3 KTY83/110
4 PT1000
̶
Tabelle 30: Specification of the temperature input for K and A control
Use only sensors with basic insulation for mains potential!
Danger to life due to electric shock!
► The inputs of the temperature detection have "basic insulation"
against SELV voltage of the control.
► A system voltage (Phase – PE) of 300 V is defined.
Malfunctions due to incorrect cable or laying!
Malfunctions of the control due to capacitive or inductive coupling.
► Do not lay the cable of the motor temperature sensor (also shielded)
together with the control cable.
► Cables from the motor temperature sensor inside the motor cable are
only permissible with double shielding.
resistance
0.49 kΩ
1 kΩ
1.72 kΩ
< 0.75 kΩ
PTC in accord-
750...1500 kΩ
ance with
EN 60947-8
1.65...4 kΩ
(standard)
> 4 kΩ
digital via the encoder channel
0.82 kΩ
1.67 kΩ
2.53 kΩ
1 kΩ
1.38 kΩ
1.75 kΩ
< 0.04 kΩ
Monitoring
> 79.5 kΩ
Temperature/status
0 °C
100 °C
200 °C
TA1-TA2 closed
Reset resistance
Tripping resistance
TA1-TA2 open
0 °C
100 °C
175 °C
0 °C
100 °C
200 °C
Short-circuit
No connection (sensor break)
