2. Function Features
ECG input channel
Background grid
Display color
Lead off Alarm
ECG waveform freeze and
replay
Support pacemaker detection
Working mode
Record mode
Display mode
Sample mode
Date mode
Input mode
Lead system
Defibrillation-proof Protection
Barcode Scanner Function
System check function
Patient records management
function
Peripheral
Local memory
Data Transmission
Report output format
Print
3. Recorder
Recorder : Thermal Dot-matrix Recorder
Resolution
Simultaneous 12 leads ECG acquisition
Background grid display on the screen
Various color options of main interface background and waveform display
When patient cable disconnected, there would be "lead off" alarm on display.
Supports ECG waveform freeze and playback up to 300seconds
Support pacemaker detection, pacemaker detection sensitivity can be ad-
justed to low and high levels.
Auto mode, Rhythm mode, Manual mode
EM-601/EM-601A/EM-601B :3 4, 3 4+1R, 3 4+3R, 6 2, 6 2+1R, 1R
EM-301/EM-301A/EM-301B : 3 4, 3 4+1R, 1R
Simultaneous or Sequential
Pre-sample, real-time sample, trigger sample, Periodic sample
ECG Mode, Demo Mode, Calibration Mode
Floating ground input, with anti defibrillation protection circuit and pulse
suppression function.
Support Standard lead system, Posterior wall lead system, R-Pectoral lead
system, R-pectoral/PW lead system, Up intercostal lead system, Down inter-
costal lead system, Cabrera lead system and User-defined lead name.
defibrillation-proof Electric Shock Protection
The patient information can be input by scanning one-dimensional and
two-dimensional barcode.
It can self-check the machine in terms of display, keyboard, file system, bat-
tery, amplify board, network, and printer.
Users can add or edit patient information. Equipped with file management
function of patient records, including delete, upload, preview, import, export,
query, print, etc.
Built-in SD card slot and USB port. Support SD card, U-disk, Keyboard, print-
er and barcode scanner
Built in memory, save up to 1000ECG report, the data can be checked on PC.
Equipped with wireless networking function, supports the transmission of
ECG data to Bluetooth ECG and PC-ECG or ECG data management software,
and supports the acquisition of appointment patient information from the
server. (optional).
Support PDF, JPEG, BMP, FDA-XML, EM-XML, SCP, BKG, DICOM and other
formats output.
1. Built-in Thermal Printer module.
2. It can be connected to designated external USB printer to print ECG re-
port on A4 paper.
3. It supports print ECG grid on paper without grids.
≥ 8 dots/mm (vertical direction)
≥40 dots/mm (25mm/s); ≥ 20 dots/mm (50 mm/s) (horizontal
direction)
