Spengler CARDIOMATE 3 Benutzerhandbuch Seite 75

ECG Classification
ECG Diagnosis
Print detailed meas-
urement parameters
Reanalysis
5.3 Communication Setup
In the Setup interface, press button【3】to enter the Communication Setup, as shown below:
The corresponding setting interface can be accessed through the digital key. The premise of
successful communication setting is that the ECG must be connected to the Internet.
IP setup
FTP setup
Shared directory
settings
DICOM setup
HL7 setup
WORKLIST setup
ECG classification will be showed in the printout files when the ECG measurement ena-
bled such as "Normal ECG".
Interpretation will be showed in the printout ECG files when ECG diagnosis is enabled.
On: print or save the current ECG detailed parameters of template of each lead dis-
played in picture.
Off: the detailed parameters of template are not displayed.
On: Reanalysis interface will be showed in auto mode once ECG acquisition is done if
Reanalysis is enabled.
Off: Acquire 10S data in auto mode and the equipment will directly print ECG analysis
interpretations.
In the IP setup interface, the default one is Auto obtained IP. If the user needs a
fixed IP, please select a static IP and input the corresponding value.
Note: When setting a static IP address, the user must ensure that the set static
IP is not consistent with the IP of other devices in the LAN.
To realize the FTP upload function, the FTP setup of ECG machine must be set
according to the FTP server information.
To achieve the shared directory upload function, the shared directory setup in
the ECG must be set. The corresponding information of shared directory setup
must be input according to shared directory of the computer.
To realize the DICOM upload function, the DICOM setup in the ECG must be
set. DICOM setup input the corresponding information based on the DICOM
server.
To access the HL7 server, the HL7 server of the ECG must be set. The specific
settings are based on the HL7 server.
To access the WORKLIST server, the WORKLIST server of the ECG must be set,
and the specific settings are based on the WORKLIST server.
