5.1.1 Thermal Printer
Press button【1】to enter thermal printer setup interface in the print setup interface. The
interface is shown as the figure below:
ECG Grids Print
On, Off
Pre-sample: 10s ECG data sampled before pressing the START/STOP key will be printed
out.
Real-time Sample: ECG data sampled after pressing the START/STOP key will be printed
out.The data will be recorded as soon as the user pressing the "START/STOP" button.
Trigger Mode: After pressing the START/STOP key, if arrhythmia ECG data is detected
Sample mode
during the acquisition process, the print will be triggered automatically. Otherwise, noth-
ing will come out.
Periodic Sample: Sample mode is in periodic for the same data. For example, if Interval is
set to 2 min, and Duration is set to 24 min, after pressing the START/STOP key, the print
will be performed every two minutes and come to 12 times.
Duration
Set the duration of periodic sample
Interval
Set the interval of periodic sample
73
