Language F1
Logo F2
Upgrade F3
Barcode F4
More F5
5.6 Filter Setup
In the Setup interface, press button【6】to enter the filter setup. At the same time, the user can
also press the filter shortcut key on the main interface to enter the filter setup.
Item
AC Filter OFF, 50Hz, 60Hz
Baseline Filter OFF, 0.05 Hz, 0.16 Hz, 0.25 Hz, 0.32 Hz, 0.5 Hz, 0.67 Hz
EMG Filter OFF, 20 Hz, 25 Hz, 30 Hz, 35 Hz, 40 Hz, 45 Hz
Low pass Filter OFF, 75 Hz, 100 Hz, 150 Hz
Enter the language switching interface, the user can set the machine language.
【F2】
Press and input the correct password to enter the LOGO setup. The set LOGO
will be displayed on the printed report. The maximum input length of LOGO setup is 16
characters.
The machine will automatically turn off when upgrading.
Note: upgrading needs to be carried out under the guidance of professionals!
In the barcode setting interface, the users can set the start address and end address
of each parameter of the patient information. External barcode scanner needed to be
connected and the barcode needed to be set.
Function button for switching to the next page of the Admin Configuration.
Description
78
