Indicators Name
A Battery Compartment Compartment for battery
B Battery Label
C Heat Emission Hole
D Product Label
The calibration output voltage and the calibration capacity of the rechargeable lithium battery pack are as fol-
lows : Calibration output voltage:14.4V; Calibration capacity : 2600mAh
If the lithium battery is not used for a long time (more than two to three months), the
user shouldfirst charge the battery when using it again.
2.3.3 Rear Panel
Indicator Name
Power Supply Sock-
A
et
B Heat Emission Hole
C Handle
2.3.4 Right Panel
The battery label indicates the rated voltage and the rated capacity of the
rechargeable lithium battery.
Path for internal heat emission
The product label indicates the product information.
Connected to power adapter
Path for internal heat emission
Portable
