ECOtwin LCD / LED

Trend Mode

Press mode button [
knob to select the 'Trend Mode' item. Press the control knob to enter the Trend mode. And, you can
search saved data.
USB Icon will RED in case data saving is ON. And 'Data Saving' will display on Message frame.
When data saving is completed USB Icon will turn to yellow and sound 'ding-dong'.

Saved Time/Date Frame

This frame shows the start and end time and date of data saving.

ID Frame

This frame shows the saved patient name and ID.

Data Searching Frame

This frame is consisted of control buttons for searching saved data. The each function of button is as
below:
Button
User manual
], then the relevant menu comes out as shown in Fig. 4.7. Rotate the control
Fig. 4.9 Trend Mode display
Searching for saved data in patient.
Selecting Previous / Next Patient
Searching for saved data in page.
Selecting Previous / Next Page
Tracing the saved graphic data
Function
30
