Rotoclear C Basic Bedienungsanleitung Seite 70

ROTOCLEAR C BASIC
Signal amplifier
Data
Torque connector data cable
Dimensions
Nominal voltage
Test voltage
Housing
Storage temperature
Operating temperature
Protection class
Operation
Mounting
Weight
Cable length
Mount
Torque joint flex arm mount
Protective hose
Dimensions
Hose
Fitting
Bending radius
Sheet metal wall thickness
1 × M12 x-coded (female) for camera head
1 × M12 x-coded (female) for control unit
0,6 Nm
Ø40 × 74 (100 incl. connector) mm
48 VDC (via data cable)
< 15 VDC (detection camera head)
stainless steel
-20 ... +60 °C permissible
+10 ... +40 °C permissible
IP67 (with data cable connected)
connected to HDMI Box
2 × external thread for M18 × 1,0
approx. 0.2 kg
max. 20 m: without signal amplifier
up to 40 m: 1 signal amplifier (2 × data cable with max. 20 m)
up to 60 m: 2 signal amplifiers (3 × data cable with max. 20 m)
5.0 Nm
1.5 m, individual length; Ø27 mm
Steel, thermal polyelastomer (TPE)
Stainless steel, M33 × 1.5
90 mm (fixed)
1-3.2 mm
69
