ROTOCLEAR C BASIC

Preparing the parts

Remove the camera system from the packaging.
When unpacking, pay attention to cleanliness.
Store all parts on a clean, shock-absorbing sur-
face or in the original packaging. Handle the prod-
uct with care. Do not touch the lens cover of the
camera head (E, Figure 2) or the safety glass of the
rotor to ensure unimpeded viewing conditions.
The camera head, especially the glass-cov-
ered front, must not be subjected to impacts, oth-
erwise the bearing unit, the rotor or other parts
may be damaged.
The camera head is covered by a plastic cap.
Remove the cap and keep it in a safe place where
it is readily available for covering the camera head
in the event of damage, thereby protecting it from
further damage.
Rotor assembly
Remove the rotor from its packaging and place it
on the center flange of the camera head. Carefully
hold the rotor in place using your hand and tight-
en the screw using a torque of 0,6 Nm. Never lock
the rotor in place using a sharp object, such as a
screwdriver. To remove the rotor, use the suction
cup provided.
Depending on the specific variant, the camera
head is pre-configured for a particular focus po-
sition. Please refer to the nameplate of the cam-
era head for the focus position. The focus position
can only be changed by the manufacturer later on
because it is sealed to keep out media, particular-
ly if the rotor fails due to damage from broken tool
or workpiece parts.
The rotor must be able to rotate freely; seal-
ing is achieved by the sealing air. Therefore, do not
install the enclosed sealing rings in the labyrinth of
the rotor outer ring under any circumstances!
These are intended for sealing at the holders. This
will impair the function and the system may be
damaged.
If adjustment of the focus is required, please
contact the manufacturer. Any attempt to open
the housing of the camera head in order to adjust
the focus position yourself will invalidate the war-
ranty.
