OPERATING MANUAL

Connection options

The HDMI box can be connected to a monitor via
HDMI. To use some functions, such as switching
the light on and off, an additional input option is re-
quired. Connect a mouse or a monitor with touch
functionality to the HDMI box via USB. In principle,
however, the device can also be operated without
an additional input interface.
Only connect monitors when switched off.
Figure 13

User interface

The control elements will be shown or hidden with
a click respectively movement of the mouse or
touch gesture on the live image. Clicking the but-
ton switches the light on or off. The state of the
light is displayed by the button.
Please note that the options, settings and
range of functions described in this chapter may
vary depending on the model or equipment vari-
ant. Availability may also depend on the software
version installed. Always ensure that the latest
available software version is installed (see chapter
"Software update").
Software update
The current version of the software is dis-
played in the lower left corner for some time after
starting the system or when clicking or touch ges-
turing.
Always ensure that the firmware of the cam-
era system is kept up to date. Each new firmware
version may include new features, improvements
and bug fixes that may also be relevant for securi-
ty and safety.
This process may take several minutes. During
this time,it will not be possible to use the camera
system. After the update is complete, the HDMI
unit will restart.
Customer service for the product can only be
provided for the current software version.
Prerequisite:
1. Software file has been downloaded from
