Open the filler plug on the top of the splitting column
so that the oil can drain off better.
Reinsert the drain screw with seal and tighten se-
curely.
Top up with new hydraulic oil. (contents: see technical
data) and check the oil level with the oil dipstick.
After changing the oil, operate the firewood splitter
several times without actually splitting.
Attention! Do not allow any dirt particles to enter
the oil container.
Dispose of the used oil properly at a local used
oil collection point. Dumping used oil in the soil
or mixing it with waste is prohibited.
We recommend oil from the HLP 32 range.
Changing the gearbox oil Fig. 20
The gearbox is filled with SAE90 gear oil at the facto-
ry. Drain the gear oil after the first 50 operating hours
and replace it with new oil as specified. The next oil
change should then be carried out every 250 operat-
ing hours or every six months, whichever comes first.
1. Disassemble the cardan shaft protective cover
and set a sufficiently large container under the
gearbox.
2. First open the oil drain screw (19) and then the
oil filler opening (17) and drain the oil completely.
3. Close the oil drain screw with a new seal and fill
new SAE90 gear oil into the filler opening using a
funnel until the lower edge of the sight glass (18)
is almost covered with oil.
Check the oil level every 8 hours. The oil level is cor-
rect when the lower edge of the sight glass (18) is
almost covered with oil.
Hydraulic system
The hydraulic system is a closed system with an oil
tank, oil pump and control valve.
The factory-completed system must not be changed
or tampered with.
Check the oil level regularly.
An oil level that is too low will damage the oil pump,
Regularly check hydraulic connections and screw
connections for leaks - retighten if necessary.
Connections and repairs
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
Please provide the following information in the
event of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Motor data - type plate
Service information
With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
Wearing parts*: Riving knife / riving spar guides, hy-
draulic oil, gear oil
* may not be included in the scope of delivery!
Spare parts and accessories can be obtained from
our Service Centre. To do this, scan the QR code on
the front page.
16. Disposal and recycling
Notes for packaging
Notes on the electrical and electronic equipment
act (ElektroG)
Waste electrical and electronic equip-
ment does not belong in household
waste, but must be collected and dis-
posed of separately!
• Used batteries or rechargeable batteries that are
not installed permanently in the old device must be
removed non-destructively before disposal! Their
disposal is regulated by the battery act.
• Owners or users of electrical and electronic devic-
es are legally obliged to return them after use.
• The end user is responsible for deleting their per-
sonal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that
waste electrical and electronic equipment must not
be disposed of with household waste.
• Waste electrical and electronic equipment can be
handed in free of charge at the following places:
- Public disposal or collection points (e.g. munici-
pal works yards)
- Points of sale of electrical appliances (stationary
and online), provided that dealers are obliged to
take them back or offer to do so voluntarily.
- Up to three waste electrical devices per type of
device, with an edge length of no more than 25
centimetres, can be returned free of charge to
the manufacturer without prior purchase of a new
device from the manufacturer or taken to another
authorised collection point in your vicinity.
- Further supplementary take-back conditions of
the manufacturers and distributors can be ob-
tained from the respective customer service.
www.scheppach.com
The packaging materials are
recyclable. Please dispose of
packaging in an environmen-
tally friendly manner.
GB | 29
