10. Start-up
Make sure that the machine is installed completely
and properly. Before each use, always check:
• the connection cables for defective areas (cracks,
cuts and the like),
• The machine for possible damage,
• Whether all screws are tightened,
• The hydraulics for leaks and
• The oil level
Check the oil level (fig. 13)
The hydraulic system is a closed system with an oil
tank, oil pump and control valve. Check the oil level
regularly before commissioning. An oil level that is
too low can damage the oil pump. The oil level must
be within the middle mark on the oil dipstick. The
splitting column must be retracted before the check,
the machine must be level. Screw in the oil dipstick
fully, to measure the oil level.
E-Motor
Check the running direction of the motor. If the split-
ting arm is not in the upper position, move the splitting
blade to the upper position using the return bow or
handles. If the splitting arm is already in the top posi-
tion, activate the splitting mechanism by moving the
two levers downwards.
This moves the splitting arm downwards.
If the splitting blade does not move despite actuating the
handles or the return bow, switch off the machine imme-
diately. Turn the pole reversing unit in the plug-in unit (Fig.
11 + 12) to change the direction of rotation of the motor.
Never allow the motor to run with the wrong di-
rection of rotation! This will inevitably lead to the
destruction of the pump system and no warranty
claim can be made for this.
Functional check
Carry out a functional check before each use.
Action:
Result:
Press both handles
Splitting blade goes down
downwards.
- until approx. 20 cm above
the table.
Release one handle
The splitting blade remains
at a time
in the selected position.
Releasing both
The splitting blade remains
handles
in the selected position.
Attention!
Loosen the filler plug (Fig. 19) before commis-
sioning.
26 | GB
Never forget to loosen the filler plug! Otherwise,
the air in the system will be repeatedly com-
pressed and depressurised, which will destroy
the seals of the hydraulic circuit and the log
splitter will no longer be usable. In this case, the
seller and the manufacturer disassociate them-
selves from any warranty claims.
Switching on/off (12)
Press the green button to switch on.
Press the red button to switch off.
Note: Before each use, always check the function of
the on-off unit by switching it on and off once.
Restart protection in the event of a power inter-
ruption (zero-voltage release)
In the event of a power failure, unintentional unplug-
ging of the plug or a defective fuse, the device switch-
es off automatically. To switch it back on again, press
the green button on the switch unit again.
Cardan shaft
• Before connecting the machine to the three-point
hitch of the drive vehicle, ensure that the weight of
the machine is suitable for the drive vehicle. The
weight of the machine can be found on the manu-
facturer's rating plate.
• The cardan shaft may only be connected when the
tractor engine is switched off.
• Only use approved cardan shafts that are suitable
for use with the log splitter. The cardan shaft must
also be equipped with all safety devices, which
must be in good condition.
• Do not stand near the cardan shaft when it is in
operation.
• Ensure that the speed on the tractor does not ex-
ceed the number specified on the rating plate, max.
540 rpm.
• Before carrying out maintenance work or if the riv-
ing knife has become jammed, first disconnect the
machine from the tractor and switch off the tractor.
Attaching splitter to drive vehicle
Fig. 13 + 14
1. Drive the drive vehicle backwards to the log splitter.
Position the lower mounting arms close enough to
the mounting pins of the firewood splitter.
2. Apply the parking brake of the drive vehicle and
switch off the engine. Block the rear wheels on
both sides with wedges or other suitable objects.
3. Remove the dust cover (1) and attach it to the
cardan shaft protective cover (2)
4. Lower the lower mounting arms to the support
pins of the firewood processor and secure them
with the locking pins. (3)
5. Position the upper mounting arm in the bracket
and align it with the holes in the bracket. Insert the
hanger pin to lock the upper mounting arm.
