20.2 Product Support and Assis‐
tance on Use
Product support and assistance on use are avail‐
able from STIHL servicing dealers.
For contacts and other information, please visit
https://support.stihl.com or www.stihl.com.

21 Specifications

21.1 STIHL RMA 7.0 RV Lawn
Mower
– Permissible battery: STIHL AP, series-connec‐
ted 72 V
– Weight without battery: 45 kg
– Weight with 2 STIHL AP 500 S batteries:
49 kg
– Cutting width: 51 cm
– Speed (n): 2600 rpm
– Speed in ECO mode: 2200 rpm
– Electrical type of protection: IPX4
– Minimum self-propulsion speed: 2 km/h
– Maximum driving speed:
– Level 1: 2 km/h
– Level 2: 3 km/h
– Level 3: 4 km/h
– Level 4: 5 km/h
– Level 5: 6 km/h
– Bluetooth
®
wireless interface
– Data connection: Bluetooth
mobile device must be compatible with
®
Bluetooth Low Energy 5.0 and support
Generic Access Profile (GAP).
– Frequency band: ISM band 2.4 GHz
– Radiated maximum transmitting power: 1
mW
– Signal Range: approx. 10 m. The signal
strength depends on the ambient conditions
and the mobile device. The working range
can vary greatly depending on external con‐
ditions, including the receiver device used.
Inside enclosed spaces and through metal‐
lic barriers (e.g. walls, shelves, suitcases),
the working range can be significantly
shorter.
– Requirements for the operating system of
the mobile device: Android or iOS (in the
current version or higher)
For information on battery life, see
www.stihl.com/battery-life .
56
®
5.1. The
21.2 Blade
– Minimum thickness a: 2.0 mm
– Minimum width b: 55 mm
– Sharpening angle c: 30°
21.3

STIHL AP battery

– Battery technology: lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
®
– Bluetooth radio interface (only for batteries
with ):
– Data connection: Bluetooth
mobile appliance must be compatible with
®
Bluetooth Low Energy 5.0 and support
Generic Access Profile (GAP).
– Frequency band: ISM band 2.4 GHz
– Maximum RF power transmitted: 1 mW
– Signal range: approx. 10 m. The signal
strength depends on the ambient conditions
and the mobile terminal. Signal range can
vary greatly depending on local conditions,
including the receiver. The range may be
perceptibly reduced inside enclosed rooms
and through metal barriers (such as walls,
shelves or cases).
– Mobile appliance operating system require‐
ments: Android or iOS (current version or
higher)
