Operating The Lawn Mower - Stihl Rma 7.0 Rv Gebrauchsanleitung

English
NOTICE
► To avoid tipping over, adjust the cutting
height first on the rear wheels and then on
the front wheels.
► Switch the lawn mower off.
The blade must not be turning.
► Place the lawn mower on a level surface.
► Pull lever (1) from the notch and move to the
desired position.
Perform this process on all 4 wheels.
13.3 Mulching
During mulching, the cut grass is chopped up
several times through a special air flow guidance
system in the mower blade area and then blown
back into the turf. The clippings remain on the
lawn surface where they partially decompose
and serve as a natural fertiliser. To ensure a per‐
fect, thick lawn, mulch regularly, removing 1/3 of
the grass height.
Requirements for good mulching results:
– Frequency: at least twice a week in the spring
(main period of growth) and once a week in
the summer and autumn.
– Cutting height: cut around a third of the grass
height.
– Mow the lawn when dry if possible.
– Use well-sharpened cutting blades.
– Select a low rate of feed.
– Vary the mowing direction and ensure that the
mowing strips overlap.
– Always mow very tall grass in stages.
48

13 Operating the Lawn Mower

► If working with self-propulsion engaged: drive
the lawn mower forwards in a controlled man‐
ner.
► If working with self-propulsion disengaged:
push the lawn mower forwards slowly and in a
controlled manner.
► If a foreign object is hit during mowing and the
blade is blocked:
► Switch off the lawn mower and remove the
batteries.
► Make sure that all moving parts have come
to a complete stop.
► Check the lawn mower.
► If repairs are required: consult a STIHL spe‐
cialist dealer.
► If the lawn mower begins to vibrate strongly:
► Switch off the lawn mower and remove the
batteries.
► Check the lawn mower.
► Check that all nuts, bolts, screws and pins
are tight.
► If repairs are required: consult a STIHL spe‐
cialist dealer.
For optimum performance, note the recommen‐
ded temperature ranges,
13.4 Mowing Modes
13.4.1 Selecting the Mowing Mode
Three mowing modes can be selected. The
selection is made via the operating unit.
– ECO mode
– Standard mode
– AUTO-BOOST mode
► Switch the lawn mower on.
► Press the button (1) to select the desired
mowing mode.
The current mode (2, 3, 4) is displayed.
ECO mode
When ECO mode is activated, the lawn mower
detects the current working conditions and
adjusts the blade speed automatically.
This may extend the battery life.
21.5.
0478-131-9676-A
