18 Maintenance
► Place to the right of the machine.
► Press lever (1) downwards with the left hand
and hold.
► Hold the lawn mower at transport handle (2)
with the right hand and upend.
The lawn mower is stable and can be cleaned.
17.3 Cleaning the Battery
► Clean the battery with a damp cloth.
17.4 Cleaning the Air Filter
► Switch the lawn mower off and remove the
battery.
► Take hold of flap by handle (1), open it as far
as it will go and hold it open.
► Clean the area around the air filter (2) with a
damp cloth or brush.
► Use both hands to release the retaining lugs
(3) one after the other. Remove the air filter (2)
by lifting it upwards.
► Remove dirt on the outside of the air filter (2)
with a soft brush.
► If the air filter (2) is damaged: Replace the air
filter (2).
► Press the air filter (2) into the upper recesses
(4) of the housing so that the locking lugs (3)
audibly snap into place.
0478-131-9676-A
The air filter (2) must be flush with the housing
all around.
NOTICE
■ The cleaning interval depends on the ambient
conditions and the working conditions.
► STIHL recommends cleaning the air filter
every 50 hours of operation.
18 Maintenance
18.1 Removing and Attaching the
Blade
18.1.1 Removing the Blade
► Switch off the lawn mower and remove the
batteries.
► Upend the lawn mower,
► Block blade (1) using a piece of wood (2).
► Unscrew the screw with washer (3) in the
direction of the arrow and remove.
► Remove blade (1).
► Dispose of the screw with washer (3).
Use a new screw with washer to attach blade.
18.1.2 Attaching the Blade
► Switch off the lawn mower and remove the
batteries.
► Upend the lawn mower,
► Apply Loctite 243 threadlocker to the thread of
the screw with washer (1).
► Position blade (2) so that the raised areas on
the contact area engage in the notches.
► Screw in the screw with washer (1).
► Block blade (2) using a piece of wood (3).
► Tighten the screw with washer (1) to 60 Nm
