English
► Press the ON button (1).
The lawn mower is switched on.
Within 3 seconds, the preset mowing mode
indicator will flash.
The LED (2) indicates the charge level of the
battery with the lower energy content.
After ten minutes without further activity, the
lawn mower will switch to sleep mode.
11.2 Activating and Deactivating the
Blade
11.2.1 Activating the Blade
► Place the lawn mower on a level surface.
► Press the ON button (1).
► Within three seconds, use left hand to push
control bar for mowing (2) fully in the direction
of handlebar (3) and hold so the thumb enclo‐
ses handlebar (3).
The blade rotates.
► Hold handlebar (3) and control bar for mow‐
ing (2) with the right hand so the thumb enclo‐
ses handlebar (3).
11.2.2 Deactivating the Blade
► Release the control bar for mowing.
► Wait until the blade is no longer turning.
► If the blade continues to turn: remove the bat‐
teries and consult a STIHL specialist dealer.
The lawn mower is defective.
11.3 Engaging and Disengaging
Self-propulsion
11.3.1 Engaging self-propulsion
Use the and buttons on the handlebar to
preselect the self-propulsion speed in 5 steps.
Pressing the button increases the self-propul‐
sion speed, pressing the
The LEDs on the control indicate the preset self-
propulsion speed. If no LED lights up, self-pro‐
pulsion is switched off.
The control bar for self-propulsion can be used to
continuously regulate the speed from 2 km/h up
to the preselected maximum speed. The further
46
button reduces it.
12 Checking the Lawn Mower and Battery
the control bar for self-propulsion is pulled
towards the handlebar, the higher the speed,
21.1.
The set speed influences the battery life. The
lower the speed, the longer the battery life.
► Place the lawn mower on a level surface.
► Switch the lawn mower on.
► Use the (1) and (2) buttons to set the desired
self-propulsion speed.
The preset self-propulsion speed can be seen
from the LEDs (3).
► Pull the control bar for self-propulsion (4) in
the direction of the handlebar (5).
The lawn mower starts moving.
11.3.2 Disengaging Self-propulsion
► Release the control bar for self-propulsion.
► Wait until the lawn mower comes to a stand‐
still.
► If the lawn mower continues moving: remove
the batteries and consult a STIHL specialist
dealer.
The lawn mower is defective.
12 Checking the Lawn Mower
and Battery
12.1

Checking the Controls

Control bar for mowing
► Remove the batteries.
► Pull the control bar for mowing fully in the
direction of the handlebar and release again.
► If the control bar for mowing is stiff or does not
spring back into the initial position: do not use
the lawn mower and consult a STIHL special‐
ist dealer.
The control bar for mowing is defective.
Control bar for self-propulsion
► Remove the batteries.
► Push the control bar for self-propulsion in the
direction of the handlebar and release again.
