3 Overview
21 Batteries
The batteries supply the lawn mower with
energy.
22 Button
The button activates the LEDs on the battery.
It enables and disables the Bluetooth® radio
interface (if present).
23 "BLUETOOTH
®
" LED (only for batteries with
)
The LED indicates whether the Bluetooth®
radio interface is enabled or disabled.
24 LEDs
The LEDs indicate the battery charge state
and faults.
# Rating plate with machine number
3.2

Operating Unit

1 ON button
This button switches the lawn mower on and,
together with the control lever for mowing,
activates the blade.
2 Mowing mode button
This button is used to change mowing modes.
3 ECO mode indicator
This LED indicates ECO mode.
4 Standard mode indicator
This LED indicates Standard mode.
5 AUTO-BOOST mode indicator
This LED indicates AUTO-BOOST mode.
6 Battery charge state indicator
When the activation button is pressed, the
LED indicates the charge state of the battery
with the lower energy content.
7 LED "BLUETOOTH"
The LED indicates whether the Bluetooth®
radio interface of the lawn mower is enabled
or disabled.
8 "BLUETOOTH
®
" button
The button activates and deactivates the
Bluetooth® interface.
0478-131-9676-A
®
9 Overheating indicator
This indicator shows overheating of the lawn
mower.
10 Fault indicator
This indicator shows faults in the lawn mower.
3.3 Self-propulsion Control
1 Button
The button is used to reduce the self-propul‐
sion speed.
2 Button
The button is used to increase the self-propul‐
sion speed.
3 Display
The LEDs indicate the set self-propulsion
speed.
3.4 Symbols
The symbols can be on the lawn mower or the
batteries and have the following meaning:
Guaranteed sound power level in
L
accordance with Directive 2000/14/EC
WA
in dB(A) for the purpose of comparing
the sound emissions of products.
Activate the blade.
Activate self-propulsion and set the
self-propulsion speed.
Increase travelling speed.
Reduce travelling speed.
Set the cutting height.
English
