4.3. DISPLAY DESCRIPTION
Symbol
This symbol indicates the communication mode to a MASTER instrument
(T2100).
This symbol is displayed when the instrument's clamp is open or not
completely closed while measuring resistance. Should this symbol be
displayed continuously, the clamp may be damaged. In this case, it is
necessary to stop measuring.
This message is displayed when, during the initial instrument's
calibration
calibration process starts once again automatically from the beginning.
This message appears on the display if, at the end of the 9 initial steps,
the instrument indicates the initial calibration process failed. Switch off
and on the instrument and perform a new calibration. If the message
appears again contact the service assistance
This symbol is shown when battery level percentage is under 25%. In
this case, measurement accuracy is not granted and batteries must be
replaced.
This
measurement.
This symbol indicates overload conditions during current measurement
(T2000).
This symbol indicates sound function is on.
This symbol indicates memory
This symbol indicates memory recall
This symbol indicates noise is present and will affect the accuracy of
resistance measurement.
CAPTION:
1. Active buzzer
2. Symbol of active Data HOLD function
3. Symbol of noise
4. Symbol of open clamp
5. Symbol of wait
6. Symbol of active RS232 (T2100)
7. Current measuring unit (T2000)
8. Resistance measuring unit
9. Battery level percentage
10. Alarm resistance unit
11. Alarm resistance threshold or battery
12. Activated alarm symbol
13. Low battery indication
14. Auto Power Off symbol
15. Active memory location
16. Memory Recall mode symbol
17. Memory data symbol
18. Main display
Fig. 2: Display description
Description of special symbols
process, the clamp is opened. After the clamp is closed, the
symbol indicates
EN – 7
level percentage value
overload conditions
location.
mode.
T2000-T2100
during resistance
.
