Endress+Hauser GM32 Betriebsanleitung Seite 73

GM32
9.3.8 Bitmap Table „Extended"
Tabelle 34 Bitmap table for extended Functions
9.3.9 Table „Operating States"
Tabelle 35 Table „Operating states"
Endress+Hauser
Additional functions, such as alarm functions are listed in Bitmap table.
Bit No. Name
0 Alarm purge air
1 Alarm optic housing temperature
2 Alarm lamp current
3 Alarm lamp integration
4 Alarm pressure (pressure < 800 hPa or pressure > 1300 hPa)
5-31 Reserved
Value Operating state
0 not defined
1 Initialisation
2 Measuring
3 Maintenance
4 RCycle
5 Check cycle
6 ZeroAdjust
7 Alignment
8 Boxmeasuring
9 Restart
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
16 Reserved
17 Reserved
18 Reserved
19 Reserved
20 Reserved
Spezifikationen
Comment
Bit=1: active
Bit=1: active;
Bit=1: active;
Bit=1: active;
Bit=1: active
B E T R I E B S A N L E I T U N G
8029937/ZVF0/V2-1/2018-02
73
