61
3. OPERATION AND FUNCTION OF THE CONTROLLER
3.4
COMMISSIONING
When the hydraulic system is filled and ready for operation, connect the power unit to the
mains.
The controller has to be connected to the power unit (pre-connected) and to the sensor module
by means of the VBus
®
.
The controller runs an initialisation phase in which the Lightwheel
®
glows red.
When the controller is commissioned or when it is reset, it will run a commissioning menu after
the initialisation phase. The commissioning menu leads the user through the most important
adjustment channels needed for operating the system.
Commissioning menu
The commissioning menu consists of the channels described in the following. In order to make
an adjustment, adjust the desired value with the Lightwheel
and confirm with the right button
®
(✓). The next channel will appear in the display.
Operation
Adjustment mode
Changing a value
Confirming a value
Next parameter
