24.2
Turning on the Device
To turn on the M2Smart
"On/Off" Button
Figure 34: "On/Off" Button
The status LED is lit green as soon as the M2Smart
operating system or the normal working environment appears on the display.
24.3
Turn off
To turn off the M2Smart
"On/Off" button (hold for three seconds).
Then a dialog appears on the right side of the display with the following options „Turn off", „Restart" and
„Screenshot". To turn off the device, confirm the "Turn off" button. If you want to cancel this dialog, click on a
free area in the display. This will cause the dialog to close.
The Status LED goes out as soon as the M2Smart
24.4
Idlemode
®
To switch the M2Smart
"On/Off" button (hold for two seconds).
In Idlemode, (system) processes minimize their power consumption in order to save energy. The display is
also switched off. This means the mobile HMI computer requires only a little power and the rechargeable
battery time can be extended.
Press the "On/Off" button briefly to return to the normal screen.
24.5
Backup Power Supply
®
After the M2Smart
HMI10 Wired has been switched on for at least 15 minutes, the backup power supply
can be used.
The backup power supply allows the M2Smart
seconds when the battery is changed, so that the battery can be changed while the application is running.
The removal of the battery is detected and a message is triggered to the operating system. This message
can be used by the applications to save important data.
The display is blacked out during this process. Once the battery has been reinserted, the display becomes
fully active again.
M2SmartSE HMI10 Wired_Bedienungs-Projektierungshandbuch_
Operating and Project Engineering Manual_V1.01_de_en
®
HMI10 Wired, use the following key:
®
HMI10 Wired, please use the following key:
HMI10 Wired to idlemode, use the following key:
®
HMI10 Wired is turned on. The home screen of the
®
HMI10 Wired is turned off.
®
HMI10 Wired to be supplied with power for up to ten
62 / 76
