STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0000nnnn 0n
FORMAT No.
01111110 7E
00000000 00
BYTE COUNT
(HIGH/LOW)
01001000 48
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
01000101 45
DATA NAME
0mmmmmmm mm
0ttttttt tt
0ttttttt tt
0ddddddd dsH
DATA
0ddddddd dsL
0ddddddd deH
0ddddddd deL
CHECK SUM
0eeeeeee ee
EOX
11110111 F7
Effect library receive is effective for programs 41–128 only.
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0010nnnn 2n
FORMAT No.
01111110 7E
Effect Library Bulk Dump Format
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0–15(Tx/Rx Channel No.1–16)
Universal Bulk Dump
72(23x2+16+10)bytes
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'E'
m=0–127(Effect Library No.1–128)
title1
: :
title16
Effect Library Memory(23x2bytes)
: :
ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
End Of Exclusive
Effect Library Bulk Dump Request Format
System Exclusive Message
Manufacturer's ID (YAMAHA)
n=0–15(Tx/Rx Channel No.1–16)
Universal Bulk Dump
