Yamaha O2R Anleitung Seite 390

01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
01001000 48
DATA NAME
0mmmmmmm mm
0ttttttt tt
0ttttttt tt
0ddddddd dsH
DATA
0ddddddd dsL
0ddddddd deH
0ddddddd deL
CHECK SUM
0eeeeeee ee
EOX
11110111 F7
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0000nnnn 1n
FORMAT NO.
01111110 7E
BYTE COUNT(H)
00000000 00
BYTE COUNT(L)
00100110 26
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
DATA NAME
01001001 49
0mmmmmmm mm
DATA
0ddddddd dsH
Channel Library Bulk Dump Format
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'H'
m=0–63(Channel Library No.1–64)
title1
:
: :
title16
Channel Library Memory(48x2bytes)
: :
ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
End Of Exclusive
Channel Library(Extended Data)
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
Universal Bulk Dump
Total 38(14*2+10)
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'I'
mm=0-63(Channel Library No.1-64)
Channel Library Extended Memory(14*2 byte)
Spezifikationen
02R Bedienungsanleitung
295
