288 Spezifikationen
Program Change Assignment Table Bulk Dump Request Format
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0010nnnn 2n
FORMAT No.
01111110 7E
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
01010000 50
DATA NAME
00100000 20
EOX
11110111 F7
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0000nnnn 0n
FORMAT No.
01111110 7E
00000000 00
BYTE COUNT
(HIGH/LOW)
01101010 6A
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
01010011 53
DATA NAME
00100000 20
0ddddddd dsH
0ddddddd dsL
DATA
0ddddddd deH
0ddddddd deL
CHECK SUM
0eeeeeee ee
EOX
11110111 F7
02R Bedienungsanleitung
System Exclusive Message
Manufacturer's ID (YAMAHA)
n=0–15(Tx/Rx Channel No.1–16)
Universal Bulk Dump
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'P'
' '
End Of Exclusive
Setup Memory Bulk Dump Format
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0–15(Tx/Rx Channel No.1–16)
Universal Bulk Dump
266(128x2+10)bytes
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'S'
' '
Setup Memory(128x2bytes)
: :
ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
End Of Exclusive
