STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0010nnnn 2n
FORMAT No.
01111110 7E
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
01001101 4D
DATA NAME
0mmmmmmm mm
EOX
11110111 F7
Scene memory transmission from the 02R is possible for programs 1–96 only.
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0000nnnn 0n
FORMAT No.
01111110 7E
BYTE COUNT
00000010 02
(HIGH/LOW)
00001010 0A
01001100 4C
01001101 4D
00100000 20
00100000 20
00111000 38
01000001 41
00110110 36
00110111 37
01010000 50
DATA NAME
00100000 20
0ddddddd dsH
0ddddddd dsL
DATA
0ddddddd deH
0ddddddd deL
CHECK SUM
0eeeeeee ee
EOX
11110111 F7
Scene Memory Bulk Dump Request Format
System Exclusive Message
Manufacturer's ID (YAMAHA)
n=0–15(Tx/Rx Channel No.1–16)
Universal Bulk Dump
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'M'
m=0–96,127(Scene Memory No.0–96,current)
End Of Exclusive
Program Change Assignment Table Bulk Dump Format
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0–15(Tx/Rx Channel No.1–16)
Universal Bulk Dump
266(128x2+10)bytes
'L'
'M'
' '
' '
'8'
'A'
'6'
'7'
'P'
' '
Program Change Table(128x2bytes)
:
:
ee=(INVERT('L'+'M'+...+dsH+...+deL)+1) AND 7Fh
End Of Exclusive
Spezifikationen
02R Bedienungsanleitung
287
