00llllll L4
EOX
11110111 F7
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0001nnnn 1n
MODEL ID
00111101 3d
PARAM TYPE
00011001 1A
DATA
0ddddddd dd
0xxxxxxx XX
0yyyyyyy YY
0eeeeeee EE
EOX
11110111 F7
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0001nnnn 1n
MODEL ID
00111101 3d
PARAM TYPE
00011011 1B
DATA
0mmfffff mf
bus send level control ( receive only)
bus8
End Of Exclusive
surround x,y ( receive only)
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
fader remote (type number)
32 (surround x, y)
0-127
0-127
edit( grab, ch)
End Of Exclusive
multiple O2Rs link
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
multiple link (type number)
data format
mm(status)
= 0 : event command
4 : setup memory change
fffff(contents)
if(mm==0) {
switch(fffff) {
case 0x00: scene memory recall
case 0x01: scene memory store(with title)
case 0x10: automix memory recall
case 0x11: automix memory store(with title)
case 0x14: automix new
case 0x15: automix undo
case 0x18: automix transport - AUTO-RECORD
case 0x19: automix transport - RECORD
case 0x1A: automix transport - PLAY
