PARAMETER CHANGE (byte operation for type number 0:edit buffer, 1:setup, 2:backup)
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0001nnnn 1n
MODEL ID
00111101 3d
PARAM TYPE
00tttttt tt
0ddddddd dd0
0ddddddd dd1
DATA
0ddddddd dd2
0ddddddd dd3
:
EOX
11110111 F7
You can modify two or more continuous bytes by increasing pairs of "data( H)" and "data(L)".
PARAMETER CHANGE (bit operation for type number 0:edit buffer)
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0001nnnn 1n
MODEL ID
00111101 3d
PARAM TYPE
01tttttt tt
0ddddddd dd0
0ddddddd dd1
DATA
0ddddddd dd2
:
EOX
11110111 F7
You can modify two or more bits in same address data.
STATUS
11110000 F0
ID No.
01000011 43
SUB STATUS
0001nnnn 1n
MODEL ID
00111101 3d
PARAM TYPE
00011000 18
0ddddddd dd0
DATA
0ddddddd dd1
0ddddddd dd2
EOX
11110111 F7
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
(type number, bit6 = 0( byte operation))
address( H) high 7 bits of 14 bits address
address( L) low 7 bits of 14 bits address
data( H) high 4 bits of 8 bits data( 0000dddd)
data( L) low 4 bits of 8 bits data( 0000dddd)
:
End Of Exclusive
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
(type number, bit6 = 1( bit operation))
address( H) high 7 bits of 14 bits address
address( L) low 7 bits of 14 bits address
data( bit0-3:change bit0-7 bit4:0=reset 1=set)
:
End Of Exclusive
PARAMETER CHANGE (recall/store)
System Exclusive Message
Manufacturer's ID No.(YAMAHA)
n=0-15(Tx/Rx Channel No.1-16)
MODEL ID (02R)
recall/store (type number)
instruction
number
channel
End Of Exclusive
