- refer to the numbers imprinted on the riving knife. The
riving knife should never be thinner than the body of the
saw blade or thicker than the cutting joint width.
• Lower the suction hood onto the workpiece during every
working cycle.
• The hood must be positioned horizontally above the saw
blade during every working cycle.
• Always use the push-stick when cutting narrow
workpieces (less than 120 mm in width) lengthwise.
• Switch off the machine during troubleshooting or to
remove jammed pieces of wood. Disconnect power
supply plug!
• Wear close-fitting garments. Do not wear jewelry, rings or
wrist-watches.
• Check direction of motor and tool rotation (refer to
"Electrical Connection").
• Machine safety equipment should not be detached or
disabled under any circumstances.
• The motor must be switched off during any conversion,
adjustment, measurement and cleaning work to the
machine. Disconnect the power supply plug and wait
until the rotating saw has come to a complete stop.
• Switch off the machine before remedying faults.
Disconnect power supply plug!
• The machine must be connected to a dust extractor at
all times during use. Follow the instructions for proper
use.
• All safety equipment and hoods must be installed to
operate the machine.
• Prior to initial operation the machine must be connected
to a dust extractor by means of a flexible, non-flammable
suction hose.
• The dust extractor should switch on automatically when
the panel sizing circular saw is activated.
• Switch off the motor when leaving the work area.
Disconnect power supply plug!
• Always disconnect the machine from all external power
sources before moving it, no matter how slightly!
Reconnect the machine to the power supply before
restarting the machine!
• Installation, repair and maintenance work on the
electrical equipment should be done by qualified
electricians only.
• All safety equipment and protective devices must be
reattached as soon as repair and maintenance work has
been completed.

Proper Use

• This machine complies with the applicable EC machine
guideline.
• This machine has a work area located in front of the
machine to the left or right of the saw blade.
• To prevent accidents the work area and the area around
the machine must be clear of any foreign objects which
could interfere with machine operation.
• Workpieces should not contain any foreign objects such
as nails or screws.
• Prior to initial operation the machine must be connected
to a dust extractor by means of a flexible, non-flammable
suction hose.
• For use in closed spaces the machine must be connected
to a dust extractor. Use a ha 3200 or ha 2600 dust
extractor to extract wood shavings or sawdust. The flow
rate at the suction connection piece should be 20 m/s.
Partial vacuum 1200 Pa.
• The automatic switch on device is available as a special
accessory.
Type ALV 2 Art. No. 7910 4010
Hz
Type ALV 10 Art. No. 7910 4020
Hz
When the machine is switched on the dust extractor
switches on automatically after a 2 - 3 second time
delay. This prevents overstress to the house fuse.
After the machine has been switched off the dust
extractor continues to run for 3 - 4 seconds before
switching off automatically.
This ensures that residual dust is extracted in accordance
with the hazardous materials ordinance. This conserves
electricity and reduces noise. The dust extractor runs
only when the machine is in operation.
For industrial work use the rg 4000 dust extractor.
Do not switch off or remove dust extractors when the
machine is in operation.
• The panel sizing circular saw is designed for use in
processing wood or wood-like materials only. Use genuine
parts and accessories only. Select the correct saw blade
according to type of cut and type of wood (solid wood,
plywood or particle board) in accordance with EN 847-
1. Refer to the special accessories list.
• The manufacturer shall not be held liable for improper
use!!

Additional Hazards

This machine is designed in accordance with state of the
art technology and accepted standards of technical safety.
In spite of this certain additional hazards may occur during
operation of this machine.
• Risk of injury to fingers and hands from rotating saw or
workpiece if saw or workpiece is routed improperly.
• Risk of injury from rotating saw resulting from improper
mounting or guide control or from operation without end
stop.
• Health risks due to excessive noise. Permissable noise
levels are exceeded during operation of the machine.
Always wear ear protection.
• Risk of injuries from defective saw blade. Check blade
condition regularly.
• Electrical hazards if improper connection cables are
used.
• In spite of all safety precautions instituted additional
unforseeable hazards may occur.
• To minimize the risk of additional hazards follow all
"safety instructions", instructions for "proper use", and
operating instructions carefully.

Special accessories

Workpiece holder
Table widening starr /Forsa 6.0
Table widening starr /Forsa 8.0/9.0
Cross table w. telescopic arm /Forsa 6.0 5472 0704
Cross table w, telescopic arm /Forsa 8.0/9.0 5472 0705
SUVA exhaust device
Automatic switch on device ALV 2
Automatic switch on device ALV 10
230 V/50
400 V/50
Art. No.
5472 0702
5472 0703
5472 0706
5472 0707
7910 4010
7910 4020
english 18
