Technical specifications
The dimensional specifications are shown in figure 7 in
EN
the first part of this manual and in the table below.
Position (fig. 2.c)
2.3
2.2
2.1
Weight of the Tracpode PRO: 11.9 kg
Length of the Tracpode PRO when folded: 1.12 m
IMPORTANT: The Tracpode PRO may be used as
a temporary anchor point (EN 795-B: 2012), which can
be fitted with fall-arrest systems conforming with
EN 363:2002), rescue lifting devices (conforming with
EN 1496:2017 type A or B outside CE), and devices
which allow working while suspended from a rope in
accordance with Directive 2001/45/EC.
If the Tracpode PRO is used as a system for lifting
loads, in accordance with EU Machinery Regulation
2006/42/EC, it must not be used simultaneously as a
temporary anchor point.
The Tracpode PRO is a CE-marked anchor point
covered by the European Regulation UE. The certificate
of conformity issued by the laboratory QUINTIN
CERTIFICATIONS (QC) covers its use in accordance
with the requirements stated in standard EN 795:2012
and TS 16415:2013.
The EU examination certificate of conformity issued
by QC exclude applications associated with other
directives. These other products require, depending on
what they are used for, a declaration of conformity with:
• Standard EN 1496:2017, rescue lifting devices.
• Directive
2001/45/EC,
devices.
• EU Machinery Regulation 2006/42/EC, CE-marked
lifting application.
1. General warning
1. Before using a Tracpode PRO, it is essential that
the user reviews and understands the information
in the manual provided by Tractel SAS, in order to
ensure safe and effective use of the equipment.
These instructions should be made available to all
users. Further copies can be supplied on request.
2. Before using this safety equipment, it is essential to
have been trained to use it. Check the condition of
associated equipment and ensure there is enough
vertical clearance.
3. The Tracpode PRO may only be used by a single
trained and competent operator or by an operator
while overseen by a trained and competent
supervisor.
8
Overall height (fig. 7, HO)
1,62 m
1,57 m
1,52 m
rope-suspended
working
Height under head (fig. 7, H)
1,51 m
1,46 m
1,41 m
4. If a Tracpode PRO is not in good visual condition
or if it has arrested a fall, all the equipment must
be inspected by Tractel SAS or by a qualified
and competent technician, from whom written
authorisation must be given to reuse the equipment.
A visual inspection is recommended before each
use.
5. No modification or addition may be made to the
equipment without prior written approval from
TRACTEL SAS. The equipment must be transported
and stored in its original packaging.
6. Any Tracpode PRO that has not been periodically
inspected within the last twelve months, or that has
arrested a fall, must not be used. It may only be
used again following a periodic re-inspection carried
out by a qualified and competent technician who will
authorise its use in writing. If these inspections and
authorisations are not carried out, the Tracpode
PRO must
be decommissioned and destroyed.
User safety is protected if the equipment is always
kept in a well-maintained state.
7. The Tracpode PRO is a fall-arrest anchor point
capable of arresting the fall of two people weighing
up to 150 kg each. The maximum operating load for
the Tracpode PRO is 150 kg.
8. If the weight of the operator, including the weight
of their equipment and tools, is between 100 kg
and 150 kg, you must ensure that the total weight
(operator, equipment + tools) does not exceed the
maximum load of each of the components of the
fall-arrest system.
9. This equipment is suitable for use on an open-air
work site and a temperature range between -40 °C
and 60 °C. Avoid contact with sharp edges, abrasive
surfaces and chemical products.
10. If the equipment will be assigned to an employee
or similar person, ensure compliance with the
applicable labour regulations.
11. The operator must be physically and mentally fit
when using this equipment. If in doubt, check with
your doctor or your occupational doctor. Pregnant
women may not use this product.
12. This equipment should not be used beyond its limits
or in any situation other than that for which it is
specified: see "4. Functions and description".
External diameter, feet (fig. 7, DE)
1,31 m
1,27 m
1,23 m
